Connector number Connector name Description Double wordDSP
K0525 SWITCH K 1.76 5th 16-bit analog switch
in function diagram: 750.4
no
no
KK0526 SWITCH KK 0.86 1st 32-bit analog switch
in function diagram: 750.2
yes
no
KK0527 SWITCH KK 0.87 2nd 32-bit analog switch
in function diagram: 750.2
yes
no
KK0528 SWITCH KK 1.20 3rd 32-bit analog switch
in function diagram: 750.2
yes
no
KK0529 SWITCH KK 1.77 4th 32-bit analog switch
in function diagram: 750.4
yes
no
KK0530 SWITCH KK 2.08 5th 32-bit analog switch
in function diagram: 750.4
yes
no
KK0531 ... KK0538 DEMUX KK 0.62 8 outputs of the 32-bit 8-fold
demultiplexer
in function diagram: 750.7
yes
no
KK0539 OutpMultiplex 1 Output of the 32-bit 8-fold multiplexer
In function diagram: 750.7
yes
no
K0540 MatWidthJ [FD784b] Moment of inertia
Material width
Can be set with U713.1
no
no
K0541 CURVE K 1.07 1st 16-bit characteristic curve
in function diagram: 755.3
no
no
K0542 CURVE K 1.33 2nd 16-bit characteristic curve
in function diagram: 755.5
no
no
K0543 CURVE K 2.09 3rd 16-bit characteristic curve
in function diagram: 755.8
no
no
K0544 DEADZONE K 0.88 Dead zone output 1
in function diagram: 755.5
no
no
KK0545 MAX KK 2.24 Output maximum selection 32-bit
in function diagram: 760.2
yes
no
KK0546 MIN KK 2.25 Output minimum selection 32-bit
in function diagram: 760.2
yes
no
KK0547 OutpMultiplex 2 Output of the second 8-fold multiplexer
In function diagram: 753
yes
no
KK0548 OutpMultiplex 3 Output of the third 8-fold multiplexer
In function diagram: 753
yes
no
KK0549 OutpMultiplex 4 Output of the fourth 8-fold multiplexer
In function diagram: 753
yes
no
K0550 TensionSetpTP [FD784b] Taper tension
Tension setpoint from taper tension
characteristic
no
no
KK0551 TRA/STOR KK 0.7 1st 32-bit tracking/storage element
in function diagram: 760.5
yes
no
KK0552 TRA/STOR KK 2.6 2nd 32-bit tracking/storage element
in function diagram: 760.8
yes
no
KK0553 STORE KK 0.77 1st 32-bit analog memory
in function diagram: 760.5
yes
no
KK0554 STORE KK 2.50 2nd 32-bit analog memory
in function diagram: 760.8
yes
no
KK0555 D.FactorD [FD784b] Diameter calculator
Diameter factor of diameter calculator
Can be used, e.g. for feeding into
setpoint channel P440.
yes
no
14
Siemens AG 6SE7087-6QX70 (Edition AL)
SIMOVERT MASTERDRIVES Compendium Motion Control
