Connector number Connector name Description Double wordDSP
KK0628 Revs/OvflExEnco The output connector of the function
block "start position motor encoder"
contains the overflow and revolution
counters for onward connection to the
correction memory elements.
yes
no
KK0629 LTrackExtEncod Spare connector for the free block
"start position external encoder"
[FD333]
yes
no
K0630 Noise Output Binary noise signal: PRBS (Pseudo
Random Binary Sequence)
no
no
KK0640 ... KK0643 SH 1.68 KK Double word connectors of first S&H
board
yes
no
K0644 ... K0651 SH 1.68 K Connectors of first S&H element no
no
KK0652 ... KK0655 SH 1.69 KK Double word connectors of second
S&H board
yes
no
K0656 ... K0663 SH 1.69 K Connectors of second S&H element no
no
KK0664 ... KK0667 SH 1.70 KK Double word connectors of third S&H
board
yes
no
K0668 ... K0675 SH 1.70 K Connectors of third S&H element no
no
KK0794 v.DecouplDIS [FD842] Register decoupling
Speed
yes
no
KK0795 phi.OffsetDIS [FD842] Register decoupling Offset
angle
yes
no
KK0796 OffAngleDIS [FD842] Register decoupling
Offset angular speed
yes
no
KK0797 CircumDEC [FD842] Register decoupling
Current circumference
yes
no
KK0798 v.SuccessorDEC [FD842] Register decoupling
Decoupling to successor
yes
no
KK0799 CircAdaptionDEC [FD842] Register decoupling
Adaptation circumference
yes
no
KK0800 StatusWordSync Connector indicates the status of the
synchronism status signal (in function
diagram 846.4).
yes
no
KK0801 Catch-up Stop Fixed connector of parameter U688.1
shutdown position
in function diagram: 837.1
yes
no
KK0802 Catch-up SetpSp Fixed connector of catch-up setpoint
speed U688.2
in function diagram: 837.1
yes
no
KK0803 v.Offset Contains the current adjusting speed
including v_inching as a percentage
referred to U607 [in function diagram
841]
yes
no
K0804 Gear Numerator Connector reserved for input of a
counter of a fixed gear factor for the
sync. operation block
in function diagram: 835.2
no
no
K0805 Gear Denomin Connector reserved for input of a
counter of a fixed gear factor for the
sync. operation block
in function diagram: 835.2
no
no
K0806 Scale X Numer Fixed connector for numerator scaling
x-axis of U623.1
in function diagram: 839.1
no
no
K0807 Scale X Denomin Fixed connector for denominator
scaling x-axis U623.2
in function diagram: 839.1
no
no
18
