Connector number Connector name Description Double wordDSP
K0808 Scale Y Numer Fixed scaling, Y-axis table,
denominator
in function diagram: 839.6
no
no
K0809 Scale Y Denomin Fixed scaling, Y-axis table,
denominator
in function diagram: 839.6
no
no
KK0810 Status_Table1 Bit 0 to 15: Number of support values
(up to last fault-free support value)
Bit 16 to 23: Fault code
Bit 24: Table reset running
Bit 25: Table transfer running
Bit 26 to Bit 29: Spare
Bit 30: Group fault
Bit 31: Transfer finished and fault-free
Fault code
0: No fault
1: Number of support values = 0 or
higher maximum number of support
points
2: Position value of master axis higher
than table width
3: Position value of master axis not
rising
4: Data block not present (M7)
5: Data block too short (M7)
Last correct support point number in
the event that an error has occurred
during transfer to the table. The next
support point is therefore the faulty
support point.
See fault code.
In function diagram: 839.2
yes
no
KK0811 Status_Table2 Bit 0 to 15: Number of support values
(up to last fault-free support value)
Bit 16 to 23: Fault code
Bit 24: Table reset running
Bit 25: Table transfer running
Bit 26 to Bit 29: Spare
Bit 30: Group fault
Bit 31: Transfer finished and fault-free
Fault code
0: No fault
1: Number of support values = 0 or
higher maximum number of support
points
2: Position value of master axis higher
than table width
3: Position value of master axis not
rising
4: Data block not present (M7)
5: Data block too short (M7)
Last correct support point number in
the event that an error has occurred
during transfer to the table. The next
support point is therefore the faulty
support point.
See fault code.
In function diagram: 839.2
yes
no
KK0812 DisplaceAngle Source for the current angle of
displacement [LU]
in function diagram: 841.7
yes
no
