Siemens simovert masterdrives - Page 973

O
E
Function diagram
87654321
fp_mc_150_e.vsd
SIMOLINK board
MASTERDRIVES MC
08.01.02
Receiving
-150 -
V2.5
Note:
Special data can only be sent
by the SL master.
Data
16 x 16 bits
Receive
channel word
1
2
3
4
6
5
7
8
9
10
11
12
13
14
15
16
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
Low
High
.01
.08
Receive
SIMOLINK
Receive telegram
Special data
8 x 16 bits
1
2
3
4
6
5
7
8
RxD
<1>
Example: P749.02 = 0.1
=> KK7035 = Transmission channel 1 from node 0
<1>
0
1
2
3
4
5
6
7
K7001 SLB Word 1
B7115 SLB Word1Bit15
K7002 SLB Word 2
B7200 SLB Word2Bit0
B7215 SLB Word2Bit15
KK7032 SLB DWord 2
K7003 SLB Word 3
B7300 SLB Word3Bit0
B7315 SLB Word3Bit15
B7100 SLB Word1Bit0
KK7033 SLB DWord 3
K7004 SLB Word 4
B7400 SLB Word4Bit0
B7415 SLB Word4Bit15
KK7035 SLB DWord 5
K7006 SLB Word 6
B7600 SLB Word6Bit0
B7615 SLB Word6Bit15
KK7034 SLB DWord 4
K7005 SLB Word 5
B7500 SLB Word5Bit0
B7515 SLB Word5Bit15
KK7036 SLB DWord 6
K7007 SLB Word 7
B7700 SLB Word7Bit0
B7715 SLB Word7Bit15
KK7037 SLB DWord 7
K7008 SLB Word 8
B7800 SLB Word8Bit0
B7815 SLB Word8Bit15
KK7038 SLB DWord 8
K7009 SLB Word 9
B7900 SLB Word9Bit0
B7915 SLB Word9Bit15
KK7039 SLB DWord 9
K7010 SLB Word 10
KK7040 SLB DWord 10
K7011 SLB Word 11
KK7041 SLB DWord 11
K7012 SLB Word 12
KK7042 SLB DWord 12
K7013 SLB Word 13
KK7043 SLB DWord 13
K7014 SLB Word 14
KK7044 SLB DWord 14
K7015 SLB Word 15
KK7045 SLB DWord 15
K7016 SLB Word 16
SLB Read Addr
0.0 ... 200.7
P749
KK7031 SLB DWord 1
K7101 SLB Special word 1
K7102 SLB Special word 2
KK7131 SLB SpecDWord 1
K7103 SLB Special word 3
K7104 SLB Special word 4
KK7133 SLB SpecDWord 3
K7105 SLB Special word 5
K7106 SLB Special word 6
KK7135 SLB SpecDWord 5
K7107 SLB Special word 7
K7108 SLB Special word 8
KK7137 SLB SpecDWord 7
KK7136 SLB SpecDWord 6
KK7134 SLB SpecDWord 4
KK7132 SLB SpecDWord 2
U950.12 = ___(4)
SLB Rcv Data
r750.01 to .16
