Function diagram
87654321
fp_mc_290_e.vsd
Setpoint channel
MASTERDRIVES MC
08.01.02
Fixed setpoints
-290 -
V2.5
0,0 %
100,0 %
200,0 %
-100,0 %
-200,0 %
50,0 %
150,0 %
-50,0 %
-150,0 %
0
1
0 0 0 0
Select FSetp Bit 1 from control word 2/Bit 21 [190.6]
Select FSetp Bit 0 from control word 2/Bit 20 [190.6]
0 0 1 1
0 1 0 0
0 1 0 1
0 1 1 0
0 1 1 1
1 0 0 0
1 0 0 1
1 0 1 0
1 0 1 1
1 1 0 0
1 1 0 1
1 1 1 0
1 1 1 1
0 0 0 1
0 0 1 0
K0000
FixConn 0%
K0001
FixConn 100%
KK0002
FixConn 200%
K0003
FixConn -100%
KK0004
FixConn -200%
K0005
FixConn 50%
K0006
FixConn 150%
K0007
FixConn -50%
K0008
FixConn -150%
B0000
FixBinector 0
B0001
FixBinector 1
B000
KK0041
Fixed setpoint 1
-200.000 ... 200.000 %
P401.F (0.000)
KK0040
Curr FixSetp
Active FSetp
r420
# Active FSetp
r419
B
P418.B (0)
Src FSetp Bit3
B
P417.B (0)
Src FSetp Bit2
KK0044
Fixed setpoint 4
-200.000 ... 200.000 %
P404.F (0.000)
KK0045
Fixed setpoint 5
-200.000 ... 200.000 %
P405.F (0.000)
KK0046
Fixed setpoint 6
-200.000 ... 200.000 %
P406.F (0.000)
KK0047
Fixed setpoint 7
-200.000 ... 200.000 %
P407.F (0.000)
KK0048
Fixed setpoint 8
-200.000 ... 200.000 %
P408.F (0.000)
KK0049
Fixed setpoint 9
-200.000 ... 200.000 %
P409.F (0.000)
KK0050
Fixed setpoint 10
-200.000 ... 200.000 %
P410.F (0.000)
KK0051
Fixed setpoint 11
-200.000 ... 200.000 %
P411.F (0.000)
KK0052
Fixed setpoint 12
-200.000 ... 200.000 %
P412.F (0.000)
KK0053
Fixed setpoint 13
-200.000 ... 200.000 %
P413.F (0.000)
KK0054
Fixed setpoint 14
-200.000 ... 200.000 %
P414.F (0.000)
KK0055
Fixed setpoint 15
-200.000 ... 200.000 %
P415.F (0.000)
KK0056
Fixed setpoint 16
-200.000 ... 200.000 %
P416.F (0.000)
KK0042
Fixed setpoint 2
-200.000 ... 200.000 %
P402.F (0.000)
KK0043
Fixed setpoint 3
-200.000 ... 200.000 %
P403.F (0.000)
n959.40 = 7
