Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
137
Signal
Description
Remark
I3.5
-
Reserved
I3.6
-
Reserved
I3.7
-
Reserved
I4.0
Handheld unit: axis X selected
Valid at a high level
I4.1
Handheld unit: axis Y selected
Valid at a high level
I4.2
Handheld unit: axis Z selected
Valid at a high level
I4.3
Handheld unit: fourth axis selected
Valid at a high level
I4.4
Handheld unit: increment X1
Valid at a high level
I4.5
Handheld unit: increment X10
Valid at a high level
I4.6
Handheld unit: increment X100
Valid at a high level
I4.7
Handheld unit: enabled
Valid at a high level
Q0.0
Working lamp
Q0.1
-
Q0.2
Chip forward
Q0.3
Chip backward
Q0.4
Cooling pump
Q0.5
Lubrication pump
Q0.6
Safety door open
Q0.7
-
Q1.0
Magazine rotating clockwise
Q1.1
Magazine rotating counter-clockwise
Q1.2
Magazine approaching spindle position
Q1.3
Magazine approaching original position
Q1.4
Tool release from the spindle
Q1.5
-
Q1.6
-
Q1.7
Handheld unit valid
Definition of user-defined keys on the MCP
User-defined key 1
Working lamp
User-defined key 2
Manual cooling
User-defined key 3
Safety door
User-defined key 4
Manual clockwise rotation of the tool magazine
User-defined key 5
Manual reset of the tool magazine
User-defined key 6
Manual counter-clockwise rotation of the tool magazine
User-defined key 7
Removing chip forward
User-defined key 8
Removing chip backward
Structure of the sample application (OB1)
Call Conditions
Subroutine Name
Description
Each scan (SM0.0)
AUX_MCP (SBR20)
Auxiliary function
First scan (SM0.1)
PLC_INI (SBR32)
PLC initialization
Each scan (SM0.0)
EMG_STOP (SBR33)
Emergency Stop control
Each scan (SM0.0)
MCP_NCK (SBR37)
Transferring MCP and HMI signals to
the NCK interface
Each scan (SM0.0)
HANDWHL (SBR39)
Selecting a hand wheel through the
interface signal DB1900.DBB1xxx
Each scan (SM0.0)
AXIS_CTL (SBR40)
Coordinate enabling control, hardware
limit, etc.
Each scan (SM0.0)
SPINDLE (SBR42)
Spindle control
Each scan (SM0.0)
COOLING (SBR44)
Cooling control
Each scan (SM0.0)
LUBRICAT (SBR45)
Lubrication control
