Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
18 6FC5397-4EP10-0BA8, 07/2018
2
Preparation before commissioning
2.1
Scope of delivery
2.1.1
System overview
The SINUMERIK 808D ADVANCED control system is an economic numerical control system for milling or turning machines.
The SINUMERIK 808D ADVANCED controller, coupled with the high performance SINAMICS V70 feed/spindle drive,
SIMOTICS S-1FL6 feed motor, and SIMOTICS M-1PH1 main motor, is able to control up to five axes including analog/digital
spindles.
Control system versions
Control system
SINUMERIK 808D ADVANCED T
SINUMERIK 808D ADVANCED M
Applicable machine tools Turning machines Milling machines
PPU Applicable soft-
ware version
V4.90 V4.90
PPU variants PPU161.
3
PPU160.
3
PPU151.
3
PPU150.
3
PPU161.
3
PPU160.
3
PPU151.
3
PPU150.
3
Panel layout Horizon-
tal
Vertical Horizon-
tal
Vertical Horizon-
tal
Vertical Horizon-
tal
Vertical
Operator panel
with English keys
√ √ √ √ √ √ √ √
Operator panel
with Chinese keys
√ √ √ √ √ √ √ √
MCP Configurable MCPs are available in the following versions:
• Horizontal MCP, with English keys and override switches
• Horizontal MCP, with Chinese keys and override switches
• Horizontal MCP, with Chinese keys and a reserved slot for the handwheel (applicable to turning machines
only)
• Vertical MCP, with English keys and a reserved slot for the handwheel
• Vertical MCP, with Chinese keys and a reserved slot for the handwheel
• Vertical MCP, with English keys and an override switch for the spindle
•
Vertical MCP, with Chinese keys and an override switch for the spindle
Number of
configura-
ble axes
Total
Up to 6
Up to 4
Up to 6
Up to 4
Standard axes
3
3
4
4
Additional axes
(license required)
3 1 2 -
Communication with drive
Drive Bus interface
Configurable drives
SINAMICS V70 feed/spindle drive
Configurable motors
SIMOTICS S-1FL6/SIMOTICS M-1PH1
√: available
