4.3
Interfaces on the MCP
4.3.1
Control elements on the MCP
Horizontal MCP
●
Variant with override switches
●
Variant with a reserved slot for the handwheel
Vertical MCP
•
Variant with an override switch for the spindle
•
Variant with a reserved slot for the handwheel
①
Reserved hole for emergency stop button
⑨
Spindle control keys
②
Tool number display
Displays the number of the currently active tool
⑩
Keys for program start, stop, and reset
③
Operating mode selection area
⑪
Pre-defined labeling strips for keys of the MCP
