Reading: data from NCK variable x (data type of the variables: 1 to 4 bytes)
1)
0: no error; 3: illegal access to object; 5: invalid address; 10: object does not exist
17.3
PI Service
17.3.1
PI service: Job
DB1200
PI service [r/w]
PLC → NCK interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
4000
Start
4001
PI index
4002
4003
4004 PI parameter 1
4006
PI parameter 2
4008
PI parameter 3
4010
PI parameter 4
4012
PI parameter 5
4014
PI parameter 6
4016
PI parameter 7
4018
PI parameter 8
4020
PI parameter 9
4022
PI parameter 10
17.3.2
PI service: Result
DB1200
Reading / writing NC data [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
5000 Error in job Job com-
pleted
5001
5002
17.4
Retentive data area
DB1400
Retentive data [r/w]
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
User data
0
User data
1
User data
2
...
...
32
...
