Cables
15.4.1
Drive Bus cable for the SINUMERIK 808D ADVANCED
Parameter
Drive Bus cable
Jacket material
PVC
Degree of protection
IP20
Number of cores
2
Operation voltage
100 V
Operation temperature, static
-40 °C to 80 °C
Shielding
Yes
Minimum bending radius, static
75 mm
Bending cycles
3000000
Oil resistance Limited mineral oil and fats resistance
EN60811-2-1 fulfilled
Flame-retardant
IEC60332-3-24 fulfilled
Certification
RoHS
15.4.2
Cables for the SINAMICS V70 servo system
Cables for the SINAMICS V70 feed servo system
Parameter
MOTION-CONNECT 300
power cable
MOTION-CONNECT 300
encoder cable
MOTION-CONNECT 300
brake cable
Jacket material
PVC
Degree of protection (motor-side
only)
IP65
Number of cores
4
10
2
Cross-section of cores 4 × 1.5 mm
2
(for FSA)
4 × 2.5 mm
2
(for FSB/FSC)
6 × 0.22 mm
2
+ 4 ×
0.25 mm
2
2 × 0.75 mm
2
Operation voltage
600 V/1000 V
30 V
30 V
Operation temperature
-25 °C to 80 °C
Shielding
Yes (coverage ≥ 85%)
Yes
Yes
Minimum bending radius, static
5 × outer diameter
Minimum bending radius, dynamic
155 mm
Bending cycles
1000000 (maximum acceleration: 2 m/s
2
;
maximum speed: 15 m/min)
Oil resistance
EN60811-2-1 fulfilled
Flame-retardant
EN60332-1-1 to 1-3 fulfilled
Certification
RoHS and CE
RoHS
RoHS
Cables for the SINAMICS V70 spindle servo system
Parameter
MOTION-CONNECT 500 power
cable
MOTION-CONNECT 300 encoder
cable
Jacket material
PVC
Degree of protection (motor-side only)
-
IP20
Number of cores
4
10
Cross-section of cores 4 × 2.5 mm
2
, 4 × 4 mm
2
, 4 ×
10 mm
2
, 4 × 16 mm
2
6 × 0.2 mm
2
+ 4 × 0.25 mm
2
Operation voltage
1000 V
30 V
Operation temperature
-20 °C to 80 °C
-30 °C to 60 °C
