Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
439
248
Interval 32 [h]
250
Time of first warning 32 [h]
252
Number of warnings to be output 32
254
Reserved 32
17.14.2
Actual data
DB9904
Actual data table [r16]
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Interval 1 [h]
2
Number of warnings to be output 1
4 Reserved_1 1
6
Reserved_2 1
8 Interval 2 [h]
10
Number of warnings to be output 2
11
Reserved_1 2
14
Reserved_2 2
...
...
248
Interval 32 [h]
250
Number of warnings to be output 32
252
Reserved_1 32
254
Reserved_2 32
17.15
User interface for ctrl energy
Energy saving profile
DB9906
Ctrl energy
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Control signals
Set time to
pre-warning
limit
Immediate-
ly activate
energy
saving
profile
1
Control signals (HMI -> PLC)
Immediate-
ly activate
energy
saving
profile
2
Signals to check/test the energy-saving profile
PLC user
signal
Master
computer
signal
3
Reserved
4
Status signal
Activation
time T1
expired
Energy
saving
profile ac-
tive
