Open the drive data list through the following softkey operations:
Select the desired parameter using the cursor keys.
Press this key to call the help information for the selected parameter.
You can further press this softkey in the current help screen to show a com
plete list of
all SINAMICS V70 parameters. In addition, you can also use the foll
owing softkey to search
for a specific parameter by number in this list:
Pressing this softkey exits the help system.
The table below lists the parameters displayed on the drive BOP only.
r0020 Speed setpoint
smoothed
- - - rpm Float - -
Displays the currently smoothed speed setpoint at the input of the speed controller or U/f char-
acteristic (after the interpolator).
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0021 Actual speed
- - - rpm Float - -
Displays the smoothed actual value of the motor speed.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0026 DC link voltage
- - - V Float - -
Displays the smoothed actual value of the DC link voltage.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0027 Absolute actual
current
- - - Arms Float - -
Displays the smoothed absolute actual current value.
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
r0029 Current actual
value field-
generating
- - - Arms Float - -
