Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
34 6FC5397-4EP10-0BA8, 07/2018
●
Connecting
2.1.5.5
Line filters
Siemens recommends you to use a filter to protect the system from high frequency noise.
The table below lists all filters recommended by Siemens:
SINAMICS V70
Recommended filter
Drive vari-
ant
Frame
size
Rated input
current (A)
Rated current
(A)
Wire gauge
(AWG)
Degree of
protection
Article number
Feed drive
FSA
1.5
5
15 to 13
IP20
6SL3203-0BE15-0VA0
FSA
3.8
5
IP20
FSB
5.8
12
15 to 14
IP20
6SL3203-0BE21-2VA0
FSB
6.6
12
IP20
FSB
9.8
12
IP20
FSC
13.8
20
11 to 10
IP20
6SL3203-0BE22-0VA0
FSC
16.5
20
IP20
Spindle
drive
FSB 13.2 12 15 to 14 IP20 6SL3203-0BE21-2VA0
FSC
16.2
24
11 to 10
IP20
6SL3000-0HE21-0AA0
FSC 24.5 24 10 to 9 IP20
FSD
37.3
36
7 to 6
IP20
6SL3000-0BE21-6DA0
FSD
47
74
5 to 4
IP20
6SL3000-0BE23-6DA1
