Siemens SINUMERIK 808D ADVANCED Series

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
49
9.
Enter a desired password in the input fields and then click this button to save.
This pa
ssword ensures that all the connection data for AMM is encrypted. The password
can be subsequently changed at any time from the menu bar.
10.
Click the
button in the toolbar or select from the main window menu as follows to call
the connection dialog box:
11.
Select the network connections option and click this button to create new conne
ction.
12.
Assign the parameters for a new network connection in the dialog box. Note that the access
level and password must be specified acc
ording to those set on the HMI.
Note:
To avoid unauthorized access of the controller, change the Siemens default pass-
words to your own ones. For more information about changing a password, see Section
"Setting the password (Page 122)".
13.
After you finish the editing, click this button to save the settings
.
14.
Click the following button or simply double
-click the connection option to establish the con-
nection.
2.3
Personal computer
A personal computer with the following basic configuration is necessary for commissioning:
● Operating system: Windows Vista (both 32-bit and 64-bit versions)/Windows 7 (both 32-bit and 64-bit versions)
● Hard drive capacity: > 40 GB
● Memory capacity: > 1 GB
● Ethernet interface: for NC, PLC, and drive commissioning
● RJ45 Ethernet cable
