Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
139
MD14512
Machine data - Hex
PLC interface address
Function
Bit 1 DB4500.DBX1020.1 Spindle disable mode (0: disable by pressing the spindle stop key; 1: disa-
ble when detecting the standstill speed)
1)
Bit 2 DB4500.DBX1020.2 Activate the first additional axis (0: disable the additional axis control; 1:
enable the additional axis control)
Bit 3 DB4500.DBX1020.3 The first additional axis as the second spindle and does not need to be
kept enabled (1: as the second spindle and does not need to be kept ena-
bled)
Bit 5 DB4500.DBX1020.5 Define the spindle override startup value (0: the startup spindle override is
always 100%; 1: recode the spindle override value of the last machine turn
off for the next startup)
Bit 6/7
DB4500.DBX1020.6/7
Define the spindle override shift speed
14512 [21] Bit 1 DB4500.DBX1021.1 Bit 1: switch of the I/O interface (0: set I0.0-I2.7/Q0.0-Q1.7 as the standard
I/O wiring in the default PLC; 1: set I6.0-I8.7/Q4.0-Q5.7 as the standard I/O
wiring in the default PLC)
Bit 2: selection of the three-color lamp function (0: deactivate; 1: activate)
Bit 3: switch of three-color lamp flashing (0: the lamp does not flash; 1: the
lamp flashes)
Bit 2
DB4500.DBX1021.2
Selection of the three-color lamp function (0: deactivate; 1: activate)
Bit 3 DB4500.DBX1021.3 Switch of three-color lamp flashing (0: the lamp does not flash; 1: the lamp
flashes)
Bit 4 DB4500.DBX1021.4 Define the spindle override, feedrate override, and rapid feedrate control
(1: spindle override and feedrate override controlled via trigger keys; rapid
feedrate is active; 0: feedrate override controlled by gray coded switch)
Bit 5 DB4500.DBX1021.5 Define the feedrate override startup value (0: the startup feedrate override
is always 100%; 1: recode the feedrate override value of the last machine
turn off for the next startup)
Note:
When you set MD14512, you can use the following key to open the editor for bit setting:
1)
When the position control mode is active, do not disable the spindle by detecting the standstill speed.
USER_DATA_FLOAT
MD14514
Machine data
- Float
PLC interface
address
Unit
Range
Function
14514[0]
DB4500.DBD2000
-
-3.40e38 to 3.40e38
Tool magazine: spindle poisoning angle
14514[1] DB4500.DBD2004 - -3.40e38 to 3.40e38 Tool magazine: preparation position of Z axis for tool
change
14514[2]
DB4500.DBD2008
-
-3.40e38 to 3.40e38
Tool magazine: tool change position of Z axis
14514[3] DB4500.DBD2012 - -3.40e38 to 3.40e38 Tool magazine: velocity of Z axis, go to tool change
position
14514[4] DB4500.DBD2016 - -3.40e38 to 3.40e38 Tool magazine: velocity of Z axis, back to tool
change preparation position
