Local variable definition
Inputs
Number of tool on the turret, only 4, 6 are permitted
Turret clamping delay time (unit: 0.1 s)
Monitor time for searching for a tool (unit: 0.1s)
Tool position signal: NC/NO
Tool position sensor (low active)
Turret motor overload (NC)
Turret CW for tool change
Turret CCW for turret clamping
Turret change status display
Error1: no turret position signal available
Error2: programmed tool exceeds turret range
Error3: tool searching time monitor time out
Error5: max tool number setting error
Assigned global variables
Position marking for turret CW rotation
Position marking for turret CCW rotation
Turret CCW rotation delay
Programmed tool number equal to the current tool number
Programmed tool number equal to zero
Monitoring the tool change buffer zone in JOG mode
Monitoring timer for tool searching
Clamping timer for turret 1
Relevant PLC machine data
Max. tool number (4 or 6)
14510 [21] 0.1 s Turret clamping time
Monitoring time for tool searching
Activating the turret function of a turning machine
14512 [21].1 - Switch of the I/O interface (0: set I0.0 to I2.7/Q0.0 to Q1.7 as the standard I/O wiring in
the default PLC; 1: set I6.0 to I8.7/Q4.0 to Q5.7 as the standard I/O wiring in the de-
