The field type generates a 2D broken line graphic control. Using the tag <ITEM> a
graphical element can be inserted into the control. Parameters
and
specify the width and height of the box.
After the control has been created, additional elements can be inserted using the
functions
,
or
. Parameter
is not evaluated for
this control.
<control name= "c_gbox1" xpos = "250" ypos="24" width="240"
height="356" fieldtype="graphicbox" refvar="val" hotlink="true"
<property ORDINATE="Y sinus" />
<property ABSCISSA="time *100 ms" />
continued
•
–
The field type generates an empty list box control.
Using the tag <ITEM> a list box element can be inserted in the list box.
The ITEM attribute
allows this element to be assigned a unique value.
For example, this can be used to identify the element.
Parameters
and
specify the width and height of the list box.
After the control has been created, additional list box elements can be inserted using
the function
,
or
. Parameter
is not evaluated for
this control.
–
The field type generates a static control, which displays the corresponding identifier
instead of numerical values.
The <ITEM> tag can be used to assign an identifier to the field.
•
A user-specific integer value can be assigned to the attribute. This value is given as part
of the FOCUS_IN message for identifying the focus field.
•
Identifier of the reference variable that can be linked to the field (optional).
•
= "TRUE" " If the value of the reference variable changes, then the field is auto-
matically updated (optional).
•
The attribute defines the display format of the specified variable.
Formatting data, see print-Tag (optional).
