Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
321
Tag identifier
Meaning
CONTROL
Continued The following properties can be changed in an operation statement. For this purpose, the
control name and property have to be specified. The property has to be separated by a point
from the control name.
• xpos
• ypos
• width
• height
• color_bk
• color_fg
• access level
• fieldtype
• itemdata
• min
• max
• default
• disable
• tooltip
• font
• factor
Syntax:
<name>.<property>
Example:
<let name="value" />
<let name="w" />
<let name="h" />
<menu name = "main">
<open_form name = "attrib_form" />
<softkey POSITION="3">
<caption>Set%nro</caption>
</softkey>
<op>
c_move.xpos = 300;
value = c_move.xpos;
h = c_move.height;
w = c_move.width;
</op>
</menu>
<form name="attrib_form">
<init>
<control name="c_move" xpos="$xpos" ypos="124" />
</init>
</form>
