Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
328 6FC5397-4EP10-0BA8, 07/2018
Tag identifier
Meaning
SOFTKEY_BACK
The tag defines the response of the softkey "Back".
The following additional actions can be defined within the softkey block:
•
navigation
•
update_controls
•
function
Syntax:
<SOFTKEY_BACK>
…
…
</SOFTKEY_BACK>
SOFTKEY_ACCEPT
The tag defines the response of the softkey "Accept".
The following additional actions can be defined within the softkey block:
•
navigation
•
update_controls
•
function
Syntax:
<SOFTKEY_ACCEPT>
…
…
</SOFTKEY_ACCEPT>
TEXT
The tag is used to display a text in the specified position.
Syntax:
<TEXT xpos = "<X position>" ypos = "<Y position>"> Text </TEXT>
Attributes:
•
xpos
X position of the top left corner
•
ypos
Y position of the top left corner
•
color
Text color (see Section "Color coding (Page 309)")
Value:
Text to be displayed
