Function name
Description
ncfunc.pi_service
Continued
Arguments:
• _N_CREATO
var1 - Tool number
• _N_DELETO
var1 - Tool number
• _N_CREACE
var1 - Tool number
var2 - Cutting edge number
• _N_DELECE
var1 - Tool number
var2 - Cutting edge number
• _N_SETUFR
No arguments
• _N_SETUDT
var1- User data area to be activated
– 1 - Tool offset data
– 2 - Active basic frame
– 3 - Active adjustable frame
• _N_FINDBL
var1 - Search mode
– 2 - Search with contour calculation
– 4 - Search for the block end point
– 1 - Block search without calculation.
• _N_FINDAB
No arguments
Example:
• Creating a tool – tool number 3
<function name="ncfunc.pi_service">_T"_N_CREATO",
3</function>
• Delete cutting edge 1 of tool 5
<function name="ncfunc.pi_service">_T"_N_DELECE", 5,
1</function>
