Installation altitude above sea
level
Factors for reducing the torque/power according to EN 60034-6
40 °C
45 °C
50 °C
3000
0.86
0.82
0.79
3500
0.82
0.79
0.75
4000
0.77
0.74
0.71
NOTICE
Damage to the motors
For surrounding air temperatures > 55 °C, please contact your local Siemens office.
The standard motors are not suitable for use in corrosive atmospheres, atmospheres with a high salt content, or in outdoor
applications; otherwise, the motors may be damaged.
Torque-speed/power-speed characteristics - SH100
1PH1101-1❑F❑:
n
N
P
N
M
N
I
N
U
N
f
N
U
max
n
2
n
max
P
s6-25%
M
s6-25%
I
s6-25%
I
max
[rpm]
[kW]
[Nm]
[A]
[V]
[Hz]
[V]
[rpm]
[rpm]
[kW]
[Nm]
[A]
[A]
1500
3.7
24
10.3
326
53.3
355
4300
10000
5.55
36
15
20.6
