Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
407
Sets the delay time for pulse suppression.
After OFF1 or OFF3 and zero speed detection, the system waits for this time to expire and the pulses are
then suppressed.
Standstill is identified in the following cases:
• The speed actual value falls below the speed threshold in p1226 and the time started after this in p1228
has expired.
• The speed setpoint falls below the speed threshold in p1226 and the time started after this in p1227 has
p1414 Speed setpoint
- - 0000 bin - U16 IM T, U
Setting for activating/de-activating the speed setpoint filter.
If only one filter is required, filter 1 should be activated and filter 2 de-activated, to avoid excessive pro-
Dependency: The individual speed setpoint filters are parameterized as of p1415.
p1415 Speed setpoint
0 2 0 - I16 IM T, U
Sets the type for speed setpoint filter 1.
• 0: Low pass: PT1
• 1: Low pass: PT2
•
2: General 2nd-order filter
• PT1 low pass: p1416
• PT2 low pass: p1417, p1418
•
General filter: p1417 ... p1420
p1416 Speed setpoint
filter 1 time con-
0.00 5000.00 0.00 ms Float IM T, U
Sets the time constant for the speed setpoint filter 1 (PT1).
This parameter is only effective if the filter is set as a PT1 low pass.
p1417 Speed setpoint
filter 1 denomi-
nator natural
0.5 16000.0 1999.0 Hz Float IM T, U
Sets the denominator natural frequency for speed setpoint filter 1 (PT2, general filter).
This parameter is only effective if the speed filter is parameterized as a PT2 low pass or as general filter.
The filter is only effective if the natural frequency is less than half of the sampling frequency.
p1418 Speed setpoint
filter 1 denomi-
0.001 10.000 0.700 - Float IM T, U
Sets the denominator damping for velocity setpoint filter 1 (PT2, general filter).
This parameter is only effective if the speed filter is parameterized as a PT2 low pass or as general filter.
p1419 Speed setpoint
filter 1 numerator
natural frequen-
0.5 16000.0 1999.0 Hz Float IM T, U
