Page #411 background imageLoading...
Page #411 background image
Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
411
Par. No.
Name
Min
Max
Factory
setting
Unit
Data type
Effective
Can be
changed
Note:
When automatically calculating the speed controller, only the motor moment of inertia is taken into account
(p0341). For higher load moments of inertia (p0342 > 1 or p1498 > 0), you are advised to check the speed
controller gain.
p1462 Speed controller integral time
adaptation speed lower
0.00 100000.0
0
20.00 ms Float IM T, U
Description:
Sets the integration time of the speed controller before the adaptation speed range (0 ... p1464).
This value corresponds to the basic setting of the integral time of the speed controller without adaptation
(p1461 = 100 %).
Dependency: p1463
p1821[0...n]
Direction of rotation
0
1
[0] 0
-
I16
IM
-
Description:
Setting to change the direction of rotation. If the parameter is changed, it reverses the direction of rotation
of the motor and the encoder actual value without changing the setpoint.
Dependency: F07434
Caution:
Changing the direction using p1820 or p1821 is not recognized by the "Safe Direction without encoder". As
a consequence, the limit provided by SDI (Safe Direction) from r9733 no longer functions.
Notice:
An appropriate fault is output for a drive data set changeover where the direction of rotation changes and
the pulses are enabled.
Note:
For operation with the phase sequence U/V/W, the direction of rotation is defined when viewing the face
side of the motor output shaft.
When changing the direction of rotation, the rotating field direction of the current controller is reversed. The
speed actual value (e.g. r0063) is also reversed so that the control sense is kept and internally causing the
direction of rotation to be reversed with the same setpoint. Further, the position actual values of the actual
encoder are reversed (e.g. r0482[0...2]).
p29000
Motor ID
0
54251
[0] 0
-
U16
IM
T
Description:
Motor type number is printed on the motor rating plate as motor ID.
For a motor with an incremental encoder, users need to manually input the parameter value, ranging from
18 to 39. For a motor with an absolute encoder, the drive automatically reads the parameter value, ranging
from 10009 to 10048.
Dependency: -
r3998[0...n]
First drive commissioning
0
65535
-
-
U16
IM
-
Description
:
Displays whether the drive still has to be commissioned for the first time.
0 = Yes
2 = No
Dependency: -
