Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
428 6FC5397-4EP10-0BA8, 07/2018
5 Contour handwheel active (bit/binary
coded)
Handwheel
2
Handwheel
1
6
7 Invert con-
tour hand-
wheel
direction
Protection
zone not
guaranteed
8
Machine-related protection zone pre-activated
Area 8
Area 7
Area 6
Area 5
Area 4
Area 3
Area 2
Area 1
9
Machine-related protection zone pre-activated
Area 10
Area 9
10
Channel-specific protection zone pre-activated
Area 8
Area 7
Area 6
Area 5
Area 4
Area 3
Area 2
Area 1
11
Channel-specific protection zone pre-activated
Area 10
Area 9
12
Machine-related protection zone violated
Area 8
Area 7
Area 6
Area 5
Area 4
Area 3
Area 2
Area 1
13
Machine-related protection zone violated
Area 10
Area 9
14
Channel-specific protection zone violated
Area 8
Area 7
Area 6
Area 5
Area 4
Area 3
Area 2
Area 1
15 Channel-specific protection zone violated
Area 10
Area 9
Status signals, axes in Work
DB3300
Signals from NCK channel [r]
NCK → PLC interface
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
1000
Axis 1 in Work
Travel command
Travel request
Handwheel active (bit/binary coded)
1)
Plus
Minus
Plus
Minus
2
1
1001
Axis 1 in Work
Machine function
2)
Continuous
traversing
Var. INC 10000 INC 1000 INC 100 INC 10 INC 1 INC
1002
1003
Contour
handwheel
direction of
rotation
inverted
1004
Axis 2 in Work
Traversing command
Travel request
Handwheel active (bit/binary coded)
Plus
Minus
Plus
Minus
2
1
