Siemens SINUMERIK 808D ADVANCED Series User Manual

Commissioning Manual
6FC5397-4EP10-0BA8, 07/2018
83
Pin
Signal
Comment
Pin
Signal
Comment
19
I5.0
Digital input
44
Q3.5
Digital output
20
I5.1
Digital input
45
Q3.6
Digital output
21
I5.2
Digital input
46
Q3.7
Digital output
22
I5.3
Digital input
47
+24 V
+24 V input
23
I5.4
Digital input
48
+24 V
+24 V input
24
I5.5
Digital input
49
+24 V
+24 V input
25
I5.6
Digital input
50
+24 V
+24 V input
Pin
Signal
Comment
Pin
Signal
Comment
1
M
External ground
26
I8.7
Digital input
2
+24 V
+24 V output
1)
27
-
Not assigned
3
I6.0
Digital input
28
-
Not assigned
4
I6.1
Digital input
29
-
Not assigned
5
I6.2
Digital input
30
-
Not assigned
6
I6.3
Digital input
31
Q4.0
Digital output
7
I6.4
Digital input
32
Q4.1
Digital output
8
I6.5
Digital input
33
Q4.2
Digital output
9
I6.6
Digital input
34
Q4.3
Digital output
10
I6.7
Digital input
35
Q4.4
Digital output
11
I7.0
Digital input
36
Q4.5
Digital output
12
I7.1
Digital input
37
Q4.6
Digital output
13
I7.2
Digital input
38
Q4.7
Digital output
14 I7.3 Digital input 39 Q5.0 Digital output
15
I7.4
Digital input
40
Q5.1
Digital output
16 I7.5 Digital input 41 Q5.2 Digital output
17
I7.6
Digital input
42
Q5.3
Digital output
18
I7.7
Digital input
43
Q5.4
Digital output
19
I8.0
Digital input
44
Q5.5
Digital output
20
I8.1
Digital input
45
Q5.6
Digital output
21
I8.2
Digital input
46
Q5.7
Digital output
22
I8.3
Digital input
47
+24 V
+24 V input
23
I8.4
Digital input
48
+24 V
+24 V input
24
I8.5
Digital input
49
+24 V
+24 V input
25
I8.6
Digital input
50
+24 V
+24 V input
1)
Make sure that the current at pin 2 of X301 or X302 does not exceed the maximum current I
out
= 0.25 A; otherwise, the
controller could be damaged.
