Entries Meaning
UpperLimit Upper input limit for these parameters in the user interface.
Only applies for numerically entered parameters.
LowerLimit Lower input limit for these parameters in the user interface.
Only applies for numerically entered parameters.
Example
In the following example, the <GeoRadius> parameter is used.
Only enter the modified data.
<PARAMETERCONFIGURATION>
<GeoRadius>
<Width value="53" type="int" />
<DisplayMode value="DoubleMode" type="QString" />
<DecimalPlaces value="2" type="int" />
</GeoRadius>
</PARAMETERCONFIGURATION>
Configuring new list parameters based on an existing list parameter.
Assign a new parameter name and enter only the changed data:
Entries Meaning
Assign new parameter name
See example 1: Text "NewGeoRadius"
Base Name of the parameter on which the new parameter is based.
See example 1: "GeoRadius" parameter is used as a template.
Also enter only the changed data here. All other data is taken from the existing
parameter.
See example 1: Column width changed to 46 pixels. Number of decimal places
changed to 1.
Example 1
<PARAMETERCONFIGURATION>
<NewGeoRadius>
<Base value="GeoRadius" type="QString" />
<Width value="46" type="int" />
<DisplayMode value="DoubleMode" type="QString" />
<DecimalPlaces value="1" type="int" />
</NewGeoRadius>
</PARAMETERCONFIGURATION>
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 193
