process:=SlHmiHost1, preload:=false, cmdline:="-settingsFile
sldm_keyboard.ini"
The application name to be used for configuration within a display configuration:
SlKeyboardApp
The application may only be used in one instance within a display configuration.
In the standard version, three sizes are pre-configured for the virtual keyboard (see file
sldm_1920x1080.ini):
[760x505]
Num= KeyboardLayout:="numpadlayout", x:=430, y:=270
Alpha= KeyboardLayout:="nclayout", x:=92, y:=50
KeyHeight=47
[1024x242]
Num= KeyboardLayout:="numpadlayout", x:=784, y:=25
Alpha= KeyboardLayout:="nclayout", x:=206, y:=25
KeyHeight=47
[824x210]
Num= KeyboardLayout:="numpadlayout", x:=584, y:=22
Alpha= KeyboardLayout:="nclayout", x:=5, y:=22
KeyHeight=47
The section name corresponds to the respective frame size (specification in pixels). The
attributes have the following meanings:
Property Description
KeyboardLayout
Layout of the virtual keyboard. Two layouts are available:
● numpadlayout: Only has keys for inputting numbers
● nclayout: Complete NC keyboard
x, y
Position of the upper left corner of the virtual keyboard in relation to the
upper left corner of the frame in which the keyboard is displayed.
KeyHeight
Height (and width) of the keys on the virtual keyboard.
If further frames with other sizes are configured in a display configuration in which the virtual
keyboard is to be shown, the file sldm_1920x1080.ini must be supplemented with the
corresponding sections and stored in the oem directory.
Virtual MCP
Configuration in the standard version:
[dialogs]
DLG111= name:=SlMcpApp,
implementation:=sldmsidescreenapp.SlSideScreenDialog,
process:=SlHmiHost1, preload:=false, cmdline:="-sidescreen1
sldmmcppage.ini"
General settings
3.14 Display Manager
SINUMERIK Operate (IM9)
68 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
