Addr. Parameter C Setting Options Default Setting
CT IN2
_:8881:106 CT 3-phase:Rated
primary current
1.0 A to 100000.0 A 1000.0 A
_:8881:113 CT 3-phase:Rated secon-
dary current
1 A to 5 A 1 A
_:8881:121 CT 3-phase:Current
range
•
1.6 x IR
•
100 x IR
1.6 x IR
_:8881:122 CT 3-phase:Internal CT
type
•
CT protection
•
CT measurement
•
CT Process bus
CT protection
CT 1
_:3841:103 CT 1:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3841:117 CT 1:Phase
•
I A
•
I B
•
I C
•
IN
•
INsens
•
Ix
_:3841:116 CT 1:Sequence number
device
1 to 2147483647 2147483647
CT 2
_:3842:103 CT 2:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3842:117 CT 2:Phase
•
I A
•
I B
•
I C
•
IN
•
INsens
•
Ix
_:3842:116 CT 2:Sequence number
device
1 to 2147483647 2147483647
CT 3
_:3843:103 CT 3:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3843:117 CT 3:Phase
•
I A
•
I B
•
I C
•
IN
•
INsens
•
Ix
_:3843:116 CT 3:Sequence number
device
1 to 2147483647 2147483647
CT 4
_:3844:103 CT 4:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3844:117 CT 4:Phase
•
I A
•
I B
•
I C
•
IN
•
INsens
•
Ix
Power-System Data
5.8 Settings
SIPROTEC 5, Fault Recorder, Manual 125
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
