Addr. Parameter C Setting Options Default Setting
_:3844:116 CT 4:Sequence number
device
1 to 2147483647 2147483647
Brk.wire det.
_:5581:1 Brk.wire det.:Mode
•
off
•
on
•
test
off
_:5581:101 Brk.wire det.:Mode of
blocking
•
blocking
•
auto blocking
•
not blocking
blocking
_:5581:102 Brk.wire det.:Delta value
for autoblock
0.004 to 5.000 1.000
Supv. balan. I
_:2491:1 Supv. balan. I:Mode
•
off
•
on
•
test
off
_:2491:101 Supv. balan. I:Release
threshold
1 A @ 100 Irated 0.030 A to 35.000 A 0.500 A
5 A @ 100 Irated 0.15 A to 175.00 A 2.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.500 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 2.500 A
_:2491:102 Supv. balan. I:Threshold
min/max
0
.
1
0
t
o
0
.
9
5
0
.
5
0
_:2491:6 Supv. balan. I:Delay failure
indication
0
.
0
0
s
t
o
1
0
0
.
0
0
s
5
.
0
0
s
Supv. ph.seq.I
_:2551:1 Supv. ph.seq.I:Mode
•
off
•
on
•
test
off
_:2551:6 Supv. ph.seq.I:Delay
failure indication
0.00 s to 100.00 s 5.00 s
Power-System Data
5.8 Settings
126 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
