Addr. Parameter C Setting Options Default Setting
_:2311:105 General:Tracking
•
inactive
•
active
inactive
_:2311:130 General:Measuring-point
ID
0 to 100 0
CT 1
_:3841:103 CT 1:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3841:117 CT 1:Phase
•
I A
•
I B
•
I C
•
IN
•
INsens
•
Ix
Measuring Point V-3ph
Addr. Parameter C Setting Options Default Setting
General
_:8911:101 VT 3-phase:Rated
primary voltage
0.200 kV to 1200.000 kV 400.000 kV
_:8911:102 VT 3-phase:Rated secon-
dary voltage
80 V to 230 V 100 V
_:8911:103 VT 3-phase:Matching
ratio Vph / VN
0.10 to 9.99 1.73
_:8911:104 VT 3-phase:VT connec-
tion
•
not assigned
•
3 ph-to-gnd volt. + VN
•
3 ph-to-gnd voltages
•
3 ph-to-ph volt. + VN
•
3 ph-to-ph voltages
3 ph-to-gnd
volt. + VN
_:8911:106 VT 3-phase:Inverted
phases
•
none
•
AC
•
BC
•
AB
none
_:8911:111 VT 3-phase:Tracking
•
inactive
•
active
active
_:8911:130 VT 3-phase:Measuring-
point ID
0 to 100 0
VT 1
_:3811:103 VT 1:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3811:108 VT 1:Phase
•
V A
•
V B
•
V C
•
V AB
•
V BC
•
V CA
•
VN
•
Vx
•
VCB
VT 2
_:3812:103 VT 2:Magnitude correc-
tion
0.010 to 10.000 1.000
Power-System Data
5.8 Settings
128 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
