Addr. Parameter C Setting Options Default Setting
_:3812:108 VT 2:Phase
•
V A
•
V B
•
V C
•
V AB
•
V BC
•
V CA
•
VN
•
Vx
•
VCB
VT 3
_:3813:103 VT 3:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3813:108 VT 3:Phase
•
V A
•
V B
•
V C
•
V AB
•
V BC
•
V CA
•
VN
•
Vx
•
VCB
VT 4
_:3814:103 VT 4:Magnitude correc-
tion
0.010 to 10.000 1.000
_:3814:108 VT 4:Phase
•
V A
•
V B
•
V C
•
V AB
•
V BC
•
V CA
•
VN
•
Vx
•
VCB
Supv. balan. V
_:2521:1 Supv. balan. V:Mode
•
off
•
on
•
test
off
_:2521:101 Supv. balan. V:Release
threshold
0.300 V to 170.000 V 50.000 V
_:2521:102 Supv. balan. V:Threshold
min/max
0.58 to 0.95 0.75
_:2521:6 Supv. balan. V:Delay
failure indication
0.00 s to 100.00 s 5.00 s
Supv. ph.seq.V
_:2581:1 Supv. ph.seq.V:Mode
•
off
•
on
•
test
off
_:2581:6 Supv. ph.seq.V:Delay
failure indication
0.00 s to 100.00 s 5.00 s
Supv. sum V
_:2461:1 Supv. sum V:Mode
•
off
•
on
•
test
off
Power-System Data
5.8 Settings
SIPROTEC 5, Fault Recorder, Manual 129
C53000-G5040-C018-5, Edition 11.2017
