NOTE
In order to establish and display the file date, the device-internal UTC time is used.
i
i
NOTE
In the mode off , the continuous recorder and the trend recorder no longer record any measured values,
but continue to record device statuses (time jumps, modes on/off, as well as disconnection and recovery
of the supply voltage).
PQDif recordings are still generated, even though the continuous recorder and the trend recorder are set to
the mode off. It is recommended to delete the instance in case of long-term non-use.
Organization of the Fast and Slow-Scan Records
Fast and slow-scan records are available via IEC 61850 in SIPROTEC format and COMTRADE format.
You can find the description of the different file formats in chapter 7.1.4 Step 3: Evaluating Recordings.
Description of the IEC 61850 Browser
The IEC 61850 Browser is a PC program that allows the IEC 61850 structure of a device to be displayed online.
It is supplied together with DIGSI 5 and during commissioning provides important information about the IEC
61850 structure of the device. The IEC 61850 browser displays datasets configured in the device, for example,
for static reports or GOOSE messages, as well as the data objects they contain.
You can find a detailed description of the IEC 61850 browser in the Communication Manual SIPROTEC 5 IEC
61850.
Fault Recorder
7.1 Introduction to DIGSI 5
230 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
