Siemens SIPROTEC 5 User Manual

Parameter: Min. active/Min.Trigger/Min. hysteresis
•
Default setting (_:9571:102) Min. active = yes
•
Default setting (_:9571:106) Min. (Non-phs sel.) = 80.000 V
•
Default setting (_:9571:121) Min. phs A(AB) = 80.000 V
•
Default setting (_:9571:122) Min. phs B(BC) = 80.000 V
•
Default setting (_:9571:123) Min. phs C(CA) = 80.000 V
•
Default setting (_:9571:114) Min. hysteresis = 1.020 p.u.
With the Min. active parameter, you activate the level trigger in order to monitor the voltage of the funda-
mental component for dropping below the set values.
Parameter Value Description
yes
The voltage of the fundamental component is monitored for undervoltage.
no
The voltage of the fundamental component is not monitored for under-
voltage.
If the Min. trigger does not operate phase-selectively, the set threshold value of the parameter Min.
(Non-phs sel.) applies to all phases.
If the Min. trigger operates phase-selectively, set the threshold values for the Min. trigger separately
for each phase. Then, the parameters Min. phs A(AB), Min. phs B(BC), and Min. phs C(CA) are
effective.
The hysteresis is preset at the factory to 1.020 p.u. (equal to 2 %) of the parameter Min. (Non-phs sel.)
and can be adjusted.
Parameter:+dM/dt active/+dM/dt/+dM/dt hysteresis
•
Default setting (_:9571:103) +dM/dt active = no
•
Default setting (_:9571:107) +dM/dt (Non-phs sel.) = 20.000 V
•
Default setting (_:9571:124) +dM/dt phs A(AB) = 20.000 V
•
Default setting (_:9571:125) +dM/dt phs B(BC) = 20.000 V
•
Default setting (_:9571:126) +dM/dt phs C(CA) = 20.000 V
•
Default setting (_:9571:115) +dM/dt hysteresis = 0.980 p.u.
•
Default setting (_:9571:112) Filter time = 2 periods
With the +dM/dt active parameter, you activate the gradient trigger in order to monitor the positive gradi-
ents of the voltage of the fundamental component using the set filtering time (input in periods).
Parameter Value
Description
yes
The positive gradient of the voltage of the fundamental component is moni-
tored.
no
The positive gradient of the voltage of the fundamental component is not
monitored.
If the gradient trigger does not operate phase-selectively, the set threshold value of the parameter +dM/dt
(Non-phs sel.) applies to all phases.
If the gradient trigger operates phase-selectively, set the threshold values for the gradient trigger separately
for each phase. Then, the parameters +dM/dt phs A(AB), +dM/dt phs B(BC), and +dM/dt phs C(CA)
are effective.
The hysteresis is preset at the factory to 0.980 p.u. (equal to 2 %) of the parameter +dM/dt (Non-phs
sel.) and can be adjusted.
Fault Recorder
7.5 Trigger Functions 3-Phase
SIPROTEC 5, Fault Recorder, Manual 301
C53000-G5040-C018-5, Edition 11.2017
