Siemens SIPROTEC 5 User Manual

Addr. Parameter C Setting Options Default Setting
_:9571:122 Trig. V fund 1:Min. phs
B(BC)
0.300 V to 340.000 V 80.000 V
_:9571:123 Trig. V fund 1:Min. phs
C(CA)
0.300 V to 340.000 V 80.000 V
_:9571:114 Trig. V fund 1:Min.
hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
dM/dt rise (/Filter time)
_:9571:103 Trig. V fund 1:+dM/dt
active
•
no
•
yes
no
_:9571:107 Trig. V fund 1:+dM/dt
(Non-phs sel.)
0.300 V to 340.000 V 20.000 V
_:9571:124 Trig. V fund 1:+dM/dt
phs A(AB)
0.300 V to 340.000 V 20.000 V
_:9571:125 Trig. V fund 1:+dM/dt
phs B(BC)
0.300 V to 340.000 V 20.000 V
_:9571:126 Trig. V fund 1:+dM/dt
phs C(CA)
0.300 V to 340.000 V 20.000 V
_:9571:115 Trig. V fund 1:+dM/dt
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
dM/dt drop (/Filter time)
_:9571:104 Trig. V fund 1:-dM/dt
active
•
no
•
yes
no
_:9571:108 Trig. V fund 1:-dM/dt
(Non-phs sel.)
0.300 V to 340.000 V 20.000 V
_:9571:127 Trig. V fund 1:-dM/dt phs
A(AB)
0.300 V to 340.000 V 20.000 V
_:9571:128 Trig. V fund 1:-dM/dt phs
B(BC)
0.300 V to 340.000 V 20.000 V
_:9571:129 Trig. V fund 1:-dM/dt phs
C(CA)
0.300 V to 340.000 V 20.000 V
_:9571:116 Trig. V fund 1:-dM/dt
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
General
_:9601:1 Trig. V RMS 1:Mode
•
off
•
on
•
test
off
_:9601:9 Trig. V RMS 1:Measured
value
•
phase-to-ground
•
phase-to-phase
phase-to-phase
_:9601:117 Trig. V RMS 1:Phase-
selective
•
no
•
yes
no
_:9601:112 Trig. V RMS 1:Filter time 2 cycles to 250 cycles 2 cycles
Max. trigger
_:9601:101 Trig. V RMS 1:Max.
active
•
no
•
yes
yes
_:9601:105 Trig. V RMS 1:Max. (Non-
phs sel.)
0.300 V to 340.000 V 120.000 V
_:9601:118 Trig. V RMS 1:Max. phs
A(AB)
0.300 V to 340.000 V 120.000 V
_:9601:119 Trig. V RMS 1:Max. phs
B(BC)
0.300 V to 340.000 V 120.000 V
Fault Recorder
7.5 Trigger Functions 3-Phase
SIPROTEC 5, Fault Recorder, Manual 309
C53000-G5040-C018-5, Edition 11.2017
