Siemens SIPROTEC 5 User Manual

Addr. Parameter C Setting Options Default Setting
_:9601:120 Trig. V RMS 1:Max. phs
C(CA)
0.300 V to 340.000 V 120.000 V
_:9601:113 Trig. V RMS 1:Max.
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
Min. trigger
_:9601:102 Trig. V RMS 1:Min. active
•
no
•
yes
yes
_:9601:106 Trig. V RMS 1:Min. (Non-
phs sel.)
0.300 V to 340.000 V 80.000 V
_:9601:121 Trig. V RMS 1:Min. phs
A(AB)
0.300 V to 340.000 V 80.000 V
_:9601:122 Trig. V RMS 1:Min. phs
B(BC)
0.300 V to 340.000 V 80.000 V
_:9601:123 Trig. V RMS 1:Min. phs
C(CA)
0.300 V to 340.000 V 80.000 V
_:9601:114 Trig. V RMS 1:Min. hyste-
resis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
dM/dt rise (/Filter time)
_:9601:103 Trig. V RMS 1:+dM/dt
active
•
no
•
yes
no
_:9601:107 Trig. V RMS 1:+dM/dt
(Non-phs sel.)
0.300 V to 340.000 V 20.000 V
_:9601:124 Trig. V RMS 1:+dM/dt
phs A(AB)
0.300 V to 340.000 V 20.000 V
_:9601:125 Trig. V RMS 1:+dM/dt
phs B(BC)
0.300 V to 340.000 V 20.000 V
_:9601:126 Trig. V RMS 1:+dM/dt
phs C(CA)
0.300 V to 340.000 V 20.000 V
_:9601:115 Trig. V RMS 1:+dM/dt
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
dM/dt drop (/Filter time)
_:9601:104 Trig. V RMS 1:-dM/dt
active
•
no
•
yes
no
_:9601:108 Trig. V RMS 1:-dM/dt
(Non-phs sel.)
0.300 V to 340.000 V 20.000 V
_:9601:127 Trig. V RMS 1:-dM/dt phs
A(AB)
0.300 V to 340.000 V 20.000 V
_:9601:128 Trig. V RMS 1:-dM/dt phs
B(BC)
0.300 V to 340.000 V 20.000 V
_:9601:129 Trig. V RMS 1:-dM/dt phs
C(CA)
0.300 V to 340.000 V 20.000 V
_:9601:116 Trig. V RMS 1:-dM/dt
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
Trigger V0 1
_:9631:1 Trigger V0 1:Mode
•
off
•
on
•
test
off
_:9631:101 Trigger V0 1:Max. trigger
active
•
no
•
yes
yes
_:9631:105 Trigger V0 1:Max. trigger 0.300 V to 340.000 V 120.000 V
Fault Recorder
7.5 Trigger Functions 3-Phase
310 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
