Addr. Parameter C Setting Options Default Setting
_:9631:113 Trigger V0 1:Max. trigger
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9631:103 Trigger V0 1:dM/dt rise
active
•
no
•
yes
no
_:9631:107 Trigger V0 1:dM/dt rise (/
Filter time)
0.300 V to 340.000 V 20.000 V
_:9631:115 Trigger V0 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9631:112 Trigger V0 1:Filter time 2 cycles to 250 cycles 2 cycles
Trigger V1 1
_:9661:1 Trigger V1 1:Mode
•
off
•
on
•
test
off
_:9661:101 Trigger V1 1:Max. trigger
active
•
no
•
yes
yes
_:9661:105 Trigger V1 1:Max. trigger 0.300 V to 340.000 V 120.000 V
_:9661:113 Trigger V1 1:Max. trigger
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9661:102 Trigger V1 1:Min. trigger
active
•
no
•
yes
yes
_:9661:106 Trigger V1 1:Min. trigger 0.300 V to 340.000 V 80.000 V
_:9661:114 Trigger V1 1:Min. trigger
hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
_:9661:103 Trigger V1 1:dM/dt rise
active
•
no
•
yes
no
_:9661:107 Trigger V1 1:dM/dt rise (/
Filter time)
0.300 V to 340.000 V 20.000 V
_:9661:115 Trigger V1 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9661:104 Trigger V1 1:dM/dt drop
active
•
no
•
yes
no
_:9661:108 Trigger V1 1:dM/dt drop
(/Filter time)
0.300 V to 340.000 V 20.000 V
_:9661:116 Trigger V1 1:dM/dt drop
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9661:112 Trigger V1 1:Filter time 2 cycles to 250 cycles 2 cycles
Trigger V2 1
_:9691:1 Trigger V2 1:Mode
•
off
•
on
•
test
off
_:9691:101 Trigger V2 1:Max. trigger
active
•
no
•
yes
yes
_:9691:105 Trigger V2 1:Max. trigger 0.300 V to 340.000 V 120.000 V
_:9691:113 Trigger V2 1:Max. trigger
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9691:103 Trigger V2 1:dM/dt rise
active
•
no
•
yes
no
_:9691:107 Trigger V2 1:dM/dt rise (/
Filter time)
0.300 V to 340.000 V 20.000 V
_:9691:115 Trigger V2 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
Fault Recorder
7.5 Trigger Functions 3-Phase
SIPROTEC 5, Fault Recorder, Manual 311
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
