Addr. Parameter C Setting Options Default Setting
_:9751:120 Trig. I fund 1:Max. phs C 1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9751:113 Trig. I fund 1:Max. hyste-
resis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
Min. trigger
_:9751:102 Trig. I fund 1:Min. active
•
no
•
yes
yes
_:9751:106 Trig. I fund 1:Min. (Non-
phs sel.)
1 A @ 100 Irated 0.030 A to 100.000 A 0.800 A
5 A @ 100 Irated 0.15 A to 500.00 A 4.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.800 A
5 A @ 50 Irated 0.15 A to 250.00 A 4.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.800 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 4.000 A
_:9751:121 Trig. I fund 1:Min. phs A 1 A @ 100 Irated 0.030 A to 100.000 A 0.800 A
5 A @ 100 Irated 0.15 A to 500.00 A 4.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.800 A
5 A @ 50 Irated 0.15 A to 250.00 A 4.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.800 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 4.000 A
_:9751:122 Trig. I fund 1:Min. phs B 1 A @ 100 Irated 0.030 A to 100.000 A 0.800 A
5 A @ 100 Irated 0.15 A to 500.00 A 4.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.800 A
5 A @ 50 Irated 0.15 A to 250.00 A 4.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.800 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 4.000 A
_:9751:123 Trig. I fund 1:Min. phs C 1 A @ 100 Irated 0.030 A to 100.000 A 0.800 A
5 A @ 100 Irated 0.15 A to 500.00 A 4.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.800 A
5 A @ 50 Irated 0.15 A to 250.00 A 4.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.800 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 4.000 A
_:9751:114 Trig. I fund 1:Min. hyste-
resis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
dM/dt rise (/Filter time)
_:9751:103 Trig. I fund 1:+dM/dt
active
•
no
•
yes
no
_:9751:107 Trig. I fund 1:+dM/dt
(Non-phs sel.)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
Fault Recorder
7.5 Trigger Functions 3-Phase
324 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
