Addr. Parameter C Setting Options Default Setting
_:9751:124 Trig. I fund 1:+dM/dt phs
A
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:125 Trig. I fund 1:+dM/dt phs
B
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:126 Trig. I fund 1:+dM/dt phs
C
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:115 Trig. I fund 1:+dM/dt
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
dM/dt drop (/Filter time)
_:9751:104 Trig. I fund 1:-dM/dt
active
•
no
•
yes
no
_:9751:108 Trig. I fund 1:-dM/dt
(Non-phs sel.)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:127 Trig. I fund 1:-dM/dt phs
A
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:128 Trig. I fund 1:-dM/dt phs
B
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:129 Trig. I fund 1:-dM/dt phs
C
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
Fault Recorder
7.5 Trigger Functions 3-Phase
SIPROTEC 5, Fault Recorder, Manual 325
C53000-G5040-C018-5, Edition 11.2017
