Data Substitute Values
Depending on the data type, different data substitute values must be used.
Data Type Possible Data Substitute Values
ACD, ACT general 0 (False), 1 (True)
(The directional information is always manually updated with
unknown .
PhsA, phsB, phsC, and neut are manually updated with the same
value just like how the general value is set.)
BAC, APC mxVal Floating-point range and range of values according to IEEE 754
(single precision)
BCR actVal
–2
63
to 2
63
– 1
CMV mag, ang Floating-point range and range of values according to IEEE 754
(single precision)
DPC, DPS stVal 0, 1, 2, 3 (intermediate-state, off, on, bad-state)
INC stVal –2 147 483 648 to 2 147 483 647
INS stVal –2 147 483 648 to 2 147 483 647
ISC, BSC valWTr.posVal –64 to 64
valWTr.transInd 0 (False), 1 (True)
SPC, SPS stVal 0 (False), 1 (True)
MV mag Floating-point range and range of values according to IEEE 754
(single precision)
For controllable types, the following substitute values apply in addition to the settable state values or meas-
ured values:
ctlNum
= 0
stSeld = False
origin.orIdent = Substituted by quality processing
origin.orCat = AUTOMATIC_BAY
Previous Quality Processing/Affected by the User for Received GOOSE Values
In the Information Routing editor, you can influence the data value and quality of all data types. The
following figure shows the possible influence using the example of a DPC data type.
•
In the DIGSI 5 project tree, double-click Information Routing.
•
Select the desired signal in the External Signals group.
•
Open the Properties window and select the Processing Quality Attributes sheet.
System Functions
3.3 Processing Quality Attributes
72 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
