Description of the software
6.6 Logic diagram
Modular Safety System 3RK3
142 System Manual, 10/2008, 926 2530-02 DS 02
6.6.4.3 Selecting
Select all
Use the menu command "Edit" > "Select all" to select all functions, connections, and
comments.
Lasso function
Use the lasso function to select all objects within a specific area:
Keep the mouse button pressed and drag open a rectangle.
All objects that are completely within the rectangle are automatically marked.
Multiple selection
● You can select several elements by pressing the Ctrl key and selecting individual
elements successively.
● The marked elements can then be moved or deleted.
6.6.4.4 Delete
Use the menu command "Edit" > "Delete" to delete one or several selected objects and
connections.
You can also delete objects/connections via the context menu (right mouse button) and the
command "Delete" or by pressing the <Del> key.
Call:
Button Command
"Edit" > "Delete"
NOTICE
Deleting an object
When you delete an object, you also delete all connections or interrupted connections that
are linked to this function.
6.6.4.5 Display of graphical conflicts
Graphical conflicts (part of a connection line/block is on top of another, connection lines that
cross over blocks, blocks on top of page margins) are automatically highlighted in red.
