Diagnostics
7.1 Diagnostics with LED
M200D PROFIBUS/PROFINET
146 Manual, 08/2014, A5E01577426A/RS-AA/004
Group fault
SF
LED
STATE LED
DEVICE LED
Group fault
Red Off Off Device diagnostics pending with enabled group
diagnostics
• Thermal motor model overload
1)
• Temperature sensor overload
1)
• Asymmetry detected
1)
• Current limit violation
1)
• Connector monitoring
1)
• Circuit breaker tripped/switched off
1)
• Group fault via input action
• Communication module removed from motor starter
module
1)
Depends on the parameter assignment
Device diagnostics
In the process input image of the starter, any pending group faults (DI 0.2) and group
warning messages (DI 0.3) are transferred cyclically. Further information about the type of
error can be accessed via a diagnostics call (system diagnostics).
All device-specific diagnostics are collected in data set 92 (29 bytes). The content of DS 92
can be read out with the help of "Motor Starter ES" via the device interface or also online via
PROFIBUS/PROFINET with the help of the "Read data set" function.
