Technical data
8.3 Brake control
M200D PROFIBUS/PROFINET
172 Manual, 08/2014, A5E01577426A/RS-AA/004
Note
Electromagnetic compatibility with pulse-shaped disturbance variables
With surges, you require a lightning protection element on the 24 V power supply. (see DP
master manual and description of SIMATIC NET PROFIBUS networks)
To change the direction of rotation, a mechanically-switching reversing contactor is
integrated in reversing starters with solid-state switching. The preferred position of this
contactor is "CW rotation". When the direction is changed to "CCW rotation", the reversing
contactor is activated first, followed by the electronic contacts after an 80 ms delay.
Rated operating voltage AC 220 ... 600 V (-10% / +5%), 50 / 60 Hz
Output voltage - 0.45 x U
e
e. g.
180 V DC at 400 V AC
215 V DC at 480 V AC
Shutdown delay - 50 ms
Continuous current < 0.5 A < 0.8 A
Voltage drop during continuous current 7 V 3.5 V
Inrush current at t < 120 ms < 5 A < 5 A
Switching capacity to IEC60947-5-1
- AC 15, at 400 V AC
- DC 13, at 180 V DC
0.4 A
-
-
0.8 A
Fault message with non-controlled brake No
Short-circuit protection Yes, 1 A melting fuse
Inductive interference protection Integrated varistors
Max. energy absorption of switching voltage limit > 43 J (for 2 ms)
