Page #169 background imageLoading...
Page #169 background image
M200D PROFIBUS/PROFINET
Manual, 08/2014, A5E01577426A/RS-AA/004
169
Technical data
8
8.1
General technical specifications
Location In the plant Wall mounted (near motor)
Permissible mounting
positions
Vertical, horizontal, flat
Degree of protection IP65
Type 12
According to IEC 529 (DIN 40050)
According to UL
Protection class 1 IEC 60364-4-41 (DIN VDE 0100-410)
Touch protection Finger-safe
Degree of pollution 3 To IEC 60664
Cooling Convection No additional cooling required
Operating temperature 25°C to + 40°C
max. 55°C
With reduction of I
e
(see "Derating")
Transport and storage
temperature
40°C to + 70°C
Air humidity 10 % to 95 % Condensation must not be allowed to form
Max. temperature change 1 K / min IEC 60068, Part 2-14
Chemical environment
conditions
3C3 conforming to IEC 60721-3-3
Installation altitude 1000 m
2000 m
No restrictions
With restrictions (reduction of I
e
by 1 % every
100 m up to 2000 m)
Vibration resistance 2 g To IEC 60 068, Part 2-6
Shock 12 g with 11 ms
without influencing point of contact:
9.8 g / 5 ms or 5.9 g / 10 ms
To IEC 60 068, Part 2-27
half-sine
Free fall 0.6 m In product packaging
ESD 8 kV air discharge
4 kV contact discharge
IEC 61000-4-2 Severity grade 3
Electromagnetic fields 10 V/m IEC 61000-4-3 Severity grade 3
BURST 2 kV / 5 kHz supply voltage
2 kV / 5 kHz data cables
2 kV / 5 kHz process cables
IEC 61000-4-4 Severity grade 3
SURGE
Installation class 1 to 3
1)
1 / 2 kV IEC 61000-4-5 Severity grade 3
Emitted interference Limit value class A EN 55011
1)
If the starter is used in installation class 3 (increased overvoltage due to parallel cable installation), an overvoltage
protection module (3RK1901-1GA00 and 3RG9030-0AA00) must be used.
