Siemens SIRIUS M200D User Manual

Appendix
A.1 Data formats and data sets
M200D PROFIBUS/PROFINET
Manual, 08/2014, A5E01577426A/RS-AA/004
201
A.1.9
DS81 Read factory setting
Data set 81 corresponds in structure and content to data set 131. Data set 81 supplies the
default values for all parameters of DS131.
A.1.10
DS92 Read device diagnostics
Object
No.
Byte.Bit
Encoding
Meaning
Relevant for
DSte / RSte
sDSSte/sRSSte
301 0.0 Bit (1 = active) Ready (automatic) All All
306 0.1 Motor CW All All
307 0.2 Motor CCW RS only RS only
309 0.3 Switching element overload All All
308 0.4 Switching element defective All All
310 0.5 Emergency start active All All
302 0.6 Group fault All All
304 0.7 Group warning All All
318 1.0 Bit (1 = active) No switching element supply voltage All All
319 1.1 No supply voltage — All
311 1.2 Lock-out time active RS only RS only
312 1.3 Starting active — All
313 1.4 Run-down active — All
315 1.5 Brake output active All with BO All with BO
324 2.0 Bit (1 = active) Temperature sensor - overload All All
325 2.1 Temperature sensor - open circuit All All
326 2.2 Temperature sensor - short circuit All All
327 2.3 Thermal motor model overload All All
328 2.4 Overload tripping All All
329 2.5 Idle time active All All
330 2.6 Cooling time active All All
333 3.2 Bit (1 = active) Circuit breaker tripped All All
320 3.3 Current limiting active — All
352 3.7 Input control All All
340 4.0 Bit (1 = active) Asymmetry detected All All
341 4.1 Asymmetry tripping All All
334 4.2 I
e
upper limit violation All All
335 4.3 I
e
lower limit violation All All
336 4.4 I
e
limit tripping All All
337 4.5 Residual current detected All All
338 4.6 Residual current tripping All All
339 4.7 Tripping due to motor blocking All All
