Ramp (3.4.1.3.)
Enables/disables ramped simulation.
Options
*
DISABLED
ENABLED
Ramp Rate (3.4.1.4.)
Sets the rate at which the simulated level will change in a ramp simulation.
Options
SLOW
1% of span
1
per second
*
MEDIUM
2% of span
1
per second
FAST 4% of span
1
per second
1)
Low Calibration Point to High Calibration Point
9.3.4.2 Discrete Inputs (3.4.2.)
Simulates behaviour of external contacts connected to a discrete input.
Discrete Input 1 (3.4.2.1.)
Disables simulation of Discrete Input 1, or sets behaviour of DI during simulation.
Options
*
DISABLED
DI is not simulated
ON
DI is simulated to be ON
OFF
DI is simulated to be OFF
Discrete Input 2 (3.4.2.2.)
Disables simulation of Discrete Input 2, or sets behaviour of DI during simulation.
Options
*
DISABLED
DI is not simulated
ON
DI is simulated to be ON
OFF
DI is simulated to be OFF
9.3.4.3 Pump Activations (3.4.3.)
Sets how physical relays (that are assigned to pumps) will behave in simulation mode.
Options
*
DISABLED
Pump relays are not activated in simulation
ENABLED
Pump relays are activated in simulation
