This section describes how the IDNet on the SPS connects to addressable
devices/detectors.
The guidelines governing IDNet wiring guidelines are covered in chpt 8, IDNet
Installation.
Up to 250 IDNet initiating devices are supported on the SPS IDNet channel. The SPS
supports both Class A (loop) and Class B(string) wiring. Class A wiring is mandatory for
connection to more than 40 devices.
Class A wiring allows IDNet appliances to communicate with the SPS even in the event
of an open circuit somewhere in the loop. Class A wiring requires that two wires are
routed from the SPS to each IDNet appliance, and then back again to the SPS.
Class B wiring allows “T” tapping, and therefore requires less wiring distance per
installation than Class A. Note that Class B wiring does not require end-of-line resistors,
because each IDNet appliance communicates directly to the SPS.
Ferrite beads are required on the SPS IDNet cables (ref Fig 7.1). Refer to chpt 8
IDNet Installation for the guidelines governing IDNet wiring.
Continued on next page
SPS IDNet Wiring
Overview
IDNet Wiring
Guidelines

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
