Two loop cards are available in the 4100U 4”x 5”card format. These plug directly onto
the PDI and form an intelligent interface between the 4100U CPU and one loop of
addressable detectors/devices.
The IDNet Card uses Mapnet Protocol and communicates with existing Mapnet
detectors/devices plus the new IDNet devices.
The 4100MXP communicates with the Tyco MX range of detectors/devices.
Refer to the page number listed in this table for information on a specific topic..
Topic See Page #
The IDNet Card
8-2
Installing the IDNet Card onto the PDI
8-4
Installing the ID-Net into a 4100 Card Bay
8-5
Configuring the Card
8-6
Wiring to IDNet Devices
8-7
Troubleshooting on IDNet
8-10
The 4100MXP
8-11
Chapter 8
Installing 4100U IDNet & 4100MXP Cards
Introduction
In this Chapter

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
