To place the 4100U FACP into operation, perform the following steps:
STEP 1 Ensure that the Mains Isolate Switch is OFF.
STEP 2 Ensure that 240 VAC is connected to the panel from the mains distribution
switchboard.
STEP 3 Ensure that the Lithium battery is fitted to battery holder on the CPU card,
and link P3 is fitted to the BAT ON position.
Turn the Mains Isolate Switch ON.
STEP 4 Check that the green "MAINS ON" LED indicator is on.
The Controller performs tests on its memory, electronics, and the LCD.
STEP 5 Check that the buzzer sounds and the LCD display “CPU Serial Number”.
STEP 6 Check that the LCD has good visibility.
STEP 7 Install and connect the batteries.
Take care not to short the battery leads or connect in reverse polarity when
connecting.
STEP 8 Press the Lamp Test key on the Operator I/F and check that all LEDs turn
on, and the LCD shows all black squares.
STEP 9 Clear all faults one at a time.
A full commissioning test should be carried out as per AS1670.1. Refer to the appendix in
this manual for detail on checking wiring, and earth fault detection. Refer to the
Operator’s Manual LT0351 for detail of the walk test that may be used for verifying
correct detector operation.
Power Up & Placing into Operation

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
