Simplex 4100U Installation & Maintenance

F-4
Simplex MAPNET 2 Range – Addressable Field Devices
2190-9156 Mapnet 2 Monitor ZAM
2190-9162 Mapnet 2 Signal ZAM
2190-9164 Mapnet 2 Control ZAM
2190-9169 Mapnet 2 Line Powered Short Circuit Isolator
2190-9172 Mapnet 2 Supervised IAM
2190-9173 Mapnet 2 Loop powered 2 Point Input / Output
Module
4099-9032NL Mapnet 2 Addressable Manual Call Point
The following lists the detectors approved for use with IDNet and shows current
rating and numbers allowed per loop.
Device Type Operating
Current mA
Maximum
Number Allowed
Per Loop
Maximum
Number
Allowed Per
Line
4098-9714E
Analogue Photoelectric
Smoke Detector
0.5
(2 with LED
on)
250 40*
4098-9717E
Analogue Ionisation
Smoke Detector
0.5
(2 with LED
on)
250 40*
4098-9733E
Analogue Heat Type A &
B Detector
0.5
(2 with LED
on)
250 40*
4098-9754E
Analogue Multi
(Heat/Photo)
Detector
0.5
(2 with LED
on)
250 40*
* Maximum allowed by AS1670.1.
The above with 9714E, 9717E and 9733E use a (4098-) 9789E addressable base
or 9794E addressable sounder base, or 9793 addressable isolator base. The
9754E uses a 9796E addressable base or 9795E sounder base.
The maximum specified loop/line resistance is 40Ω.
The maximum number of LEDs switched on by an IDNet in alarm is 20.
List of Approved Devices, Continued
Compatible Detectors, IDNET

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
