Simplex 4100U Installation & Maintenance

1-8
The following is a list of existing 4100+/A cards and modules that may be used with
4100U.
• 4100-5004 8 AZF Monitor Zone
• 4100-0113 Dual RS232 Modem Interface
• 4100-0110 MAPNET 2 Addressable Loop
• 4100-3003 8 Relay Module
• 4100-4321 6 Supervised Relays
• 4100-3024 24 Relay Module
• 4100-0302 24 I/O Module
• 4100-0111 Quad Isolator Module
• 4100-0149 Modular Network Card (required 2 media cards)
• 4100-0142 Wired Media Card RS485
• 4100-0143 Fibre Optic Media Card
• 4100-0301 LED Switch Controller
• 4100-0154 VESDA High Level Interface
• 4100-0157A 4100A PSU
• 4100-0451 Printer
• 4100-0301 64/64 LED/Switch Controller
• 4100-0302 24-Point I/O Graphic Interface
• 4100-0401 8-LED Display Card (Red LEDs)
• 4100-0402 16-Point Display Card (Red/Yellow LEDs)
• 4100-0403 8-Switch/8-LED Display Card (Momentary switches; red LEDs)
• 4100-0404 8-Switch/16-LED Display Card (Maintained switches; one red and
one green LED per switch)
• 4100-0405 8-Switch/16-LED Display Card (Maintained switches; one red and
one yellow LED per switch)
• 4100-0408 8-Switch/8-LED Annunciator Control Switch Module
• 4100-0450 Remote Panel LCD
4100 PIDs (Non-4100U)
Annunciation
Modules

Simplex 4100U Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Max Signaling Line Circuits (SLC)	2
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	10% to 93% non-condensing
Network Capability	Yes
Communication Protocol	RS-232, RS-485
Battery Backup	24 VDC
NAC Outputs	4
Signaling Line Circuits (SLCs)	2
Power Supply Current	3.0 A
Max Notification Appliance Circuits (NAC)	4
Max Releasing Circuits	4
Max Relay Circuits	4
Communication Ports	RS-232, RS-485
